--- title: Altair at CWIEME 2019 --- [![Altair Engineering Inc. logo](https://altair.com/images/default-source/default-album/footerlogo.svg) ](https://www.altair.com) [Terms of Use](https://www.siemens.com/global/en/general/terms-of-use.html) |  [Privacy Notice](https://www.sw.siemens.com/en-US/privacy-policy/) |  [Data Privacy Framework](https://altair.com/privacy-framework) |  [Cookie Notice](https://altair.com/cookie-notice) |  [DMCA](https://sw.siemens.com/en-US/dmca) |  [Whistleblowing](https://www.siemens.com/global/en/company/about/compliance/reporting-channels.html) |  Cookie Consent © Altair Engineering Inc. All Rights Reserved. ![CWIEMELPHEADER_new](https://web.altair.com/hs-fs/hubfs/2019_Germany/05_CWIEME/CWIEMELPHEADER_new.jpg?width=2000&name=CWIEMELPHEADER_new.jpg) - [Agenda of Altair Mini Event](https://web.altair.com/altair-at-cwieme-2019#hs_cos_wrapper_widget_1552056087314) - [Make an Appointment at the Booth](https://web.altair.com/altair-at-cwieme-2019#hs_cos_wrapper_widget_8025636187) - [Webinar with CWIEME and Elaphe](https://web.altair.com/elaphe-electric-motors?hsLang=en-us) ## Altair at CWIEME 2019 Altair is [the official Simulation-Driven Innovation™ partner](https://www.coilwindingexpo.com/berlin/knowledge-hub/altair-named-official-simulation-driven-innovation-partner-of-cwieme-berlin-2019?&sortby=customfield_2121%20desc%20,customfield_2121%20asc&searchgroup=libraryentry-knowledge) at this year's CWIEME Berlin. During the event we will be hosting an **Altair Mini Event "Simulation-driven Innovation for Electric Machines"** featuring customer presentations from **Elaphe Propulsion, Gulplug, Vortex Bladeless **and** Moving Magnet Technologies**.   On all three days we will also present our Innovation Solutions for E-Mobility and Electric Machines at our booth can **hall 3.1 (CWIEME's dedicated E-Mobility hall) at booth 31D10**.   If you are interested in Altair's solutions for E-Mobility, please also visit Dr. Lars Fredriksson's Keynote Innovator presentation "**E-Motor Design using Multi-Physics Optimization**", based on a use case of Porsche on CWIEME's E-mobility stage. The presentation takes place on May 23rd at 9:45 am.   ## Highlight before the CWIEME: On-demand webinar in collaboration with Elaphe Propulsion and CWIEME Berlin:    [![New call-to-action](https://no-cache.hubspot.com/cta/default/47251/29779166-c6f6-4206-9277-3a0defe26ca9.png)](https://cta-redirect.hubspot.com/cta/redirect/47251/29779166-c6f6-4206-9277-3a0defe26ca9) ### Altair Mini Event: Simulation-driven Innovation for Electrical Machines The electrification of functions in transportation is bringing new challenges to the design of electric machines. Often high-speed for compactness and controlled by PWM techniques, electric machines have to be efficient throughout a wide range of torques and speeds to save battery energy over driving cycles. To face these challenges, new technologies and topologies have to be found. Simulation and optimization tools are evolving to help provide innovative solutions. Electromagnetic simulation is at the heart of what should be modelled, but other constraints such as those coming from thermal effects, vibrations, structural stress and overall system requirements have also to be considered. During the Mini-Event **"Simulation Driven Innovation for Electrical Machines"** on **May 21st at 2:00 pm on the CWIEME Central Stage** our customers and experts will be presenting how they have used our Simulation-Driven Design solutions to help further their development of innovative products. ### Agenda:   | ![Vincent](https://web.altair.com/hs-fs/hubfs/2019_Germany/05_CWIEME/Vincent.png?width=200&name=Vincent.png) | Vincent Leconte Director of Program Management, *Altair* ### Welcome - Simulation-driven Innovation for Electrical Machines As time-to-market is key for success, the tools have to offer a streamlined optimization process, allowing to search the design space widely and efficiently, helping motor designers to meet all kinds of multiphysics constraints. Altair, with its Simulation-driven Innovation solutions offers this kind of multiphysics environment. From 1D to 3D, Altair HyperWorks can be used at different stages within the development process, to deal with all kinds of challenges the design of electric machines may imply. --- | | --- | --- | | ![Batiste Galmes](https://web.altair.com/hs-fs/hubfs/2019_Germany/05_CWIEME/Batiste%20Galmes.png?width=200&name=Batiste%20Galmes.png) | Dr. Batiste Galmès R&D engineer of the Advanced R&D department,* Moving Magnet Technologies* ### Acoustic optimization for concentrate winding BLDC motors In this talk, we introduce a novel stator topology for a permanent magnet synchronous machine dedicated to high speed applications. Thanks to finite element analysis, this stator has been designed as a compromise between the acoustic care, the mechanical performances, and the mass production feasibility. The novel topology can be seen as an improvement of an existing architecture fulfilling the last two points. | | ![Vortex](https://web.altair.com/hs-fs/hubfs/2019_Germany/05_CWIEME/Vortex.png?width=200&name=Vortex.png) | --- Jose F. Viyeira Martínez R&D Engineer, *Vortex Bladeless* ### Vortex Bladeless, Wind Energy Without Blades Vortex Bladeless is developing a technology that extracts energy from the wind thank to Vortex Shedding and Vortex Induced Vibrations (VIV). Among others, the main fields of investigation we are working on are CFD, FEA and Electromagnetic Interactions. Within our technology, these fields are all connected, so one affects the others. For that, Altair’s suite software is helping us not only to understand the phenomena. It is so important that we consider Altair as a part of the process of maturation of the technology. Thus: - Acusolve is helping us to understand the aeroelastic phenomena of VIV and to improve the shape of the device in order to be able to extract as much energy as possible from the wind. - We use Flux to design the part inside the device that transforms the energy extracted from the wind into electricity. --- | | ![GG](https://web.altair.com/hs-fs/hubfs/2019_Germany/05_CWIEME/GG.png?width=200&name=GG.png) | Gorazd Gotovac, CTO, *Elaphe Propulsion* ### Power Density with Low Noise and Vibration – Innovative In-wheel Electric Motor NVH is becoming one of the key aspects of electric mobility and in-wheel motors are no exception. With its high torque and high performance, in-wheel motors can cover a wide range of vehicle applications. At the same time, these high-power electric machines need to be designed in the right way in order to meet increasingly strict NVH regulations. In order to predict the NVH performance of the in-wheel motor, Elaphe has developed its own simulation methodology. Combined with NVH optimization algorithms developed inhouse and using Altair products, Elaphe has managed to greatly improve the overall NVH performance of its motor. --- | | ![Vincent](https://web.altair.com/hs-fs/hubfs/2019_Germany/05_CWIEME/Vincent.png?width=200&name=Vincent.png) | Vincent Leconte Director of Program Management, *Altair (France)* ### Wrap Up | | ![Panal2](https://web.altair.com/hs-fs/hubfs/2019_Germany/05_CWIEME/Panal2.png?width=200&name=Panal2.png) | --- ### Panel Discussion with  - **Batiste Galmès,** R&D Engineer, *Moving Magnet* - **Gorazd Gotovac**, CTO, *Elaphe Propulsion* - **Diego José Palomar Trullén**, R&D Engineer, *Vortex Bladeless* - **Vincent Leconte**, Director of Program Management, *Altair*       |   ---     ## Agenda Agenda description text Agenda description text bottom [![More on E-Mobility](https://no-cache.hubspot.com/cta/default/47251/f53d7f3f-35cf-406a-9828-e419d992080f.png)](https://cta-redirect.hubspot.com/cta/redirect/47251/f53d7f3f-35cf-406a-9828-e419d992080f) ### Altair's Booth Presence: Innovation Solutions for E-Mobilty & Electric Machines At the CWIEME Altair booth in **hall 3.1 (e-mobility hall), booth 31D10** visitors can experience Altair's solutions for simulation-driven design and multi-physics optimization of electric machinery, including e-motors, power grids, generators, and transformers. A special focus will be on solutions for e-mobility, featuring case studies from **Elaphe, Gulplug, Porsche** and white papers on e-motors and model based development.   ### Make an Appointment   --- **Altair is official Simulation-Driven Innovation™ Partner at this year's CWIEME Berlin** [![CWIEME-BERLIN-2019](https://web.altair.com/hs-fs/hubfs/CWIEME-BERLIN-2019-STACKED-+-LOCKUP.jpg?width=1106&name=CWIEME-BERLIN-2019-STACKED-+-LOCKUP.jpg "CWIEME-BERLIN-2019")](https://www.coilwindingexpo.com/BERLIN)
