The automotive industry is evolving at an unprecedented pace; a transformation driven by simulation. Our technologies are changing the way vehicles of all types are designed.

Do send us request for webinar recordings at marketing-asean@altair.com

Thanks much!

In this webinar, we will introduce you to the newly improved user experience of Altair HyperWorks 2020.  This new interface provides a modern environment for high-fidelity computer-aided engineering (CAE) modelling and visualisation, making learning easy and productivity high. Attendees will learn new workflows for meshing, modelling, and morphing.

The presentation will showcase:

• Brand new workflows for geometry creation and editing
• Midmeshing and interactive batch meshing
• Free direct morphing

In this webinar we will talk about all CFD solvers in Altair (AcuSolve, UltraFluidX, nanoFluidX) , especially, comparisons with legacy CFD solvers first.

And after above, we will show you some attractive use cases which can understand suitable applications for each CFD solver, for example;

• AcuSolve is suitable to solve FSI (Fluid-Structure Interaction) problem
• AcuSolve is suitable to solve thermal management
• AcuSolve is suitable to solve acoustics
• UltraFluidX is suitable to solve external aerodynamics of automotive
• nanoFLuidX is suitable to solve fluid dynamic phenomena of complex gears motion

Agenda :

agenda

1. Why do you continue using legacy CFD code?
2. Check the latest CFD codes

           2.1 kinds of the CFD solver

          2.2 CFD solvers in Altair Engineering

          2.3 FEM .VS. FVM

          2.4 Multi-Physics challenges

3. Use Cases by AcuSolve
4. Introduction of the particle based CFD codes on GPU
5. Pre-Processors for CFD

In this webinar, we will introduce you to Altair HyperView, a complete post-processing and visualization environment for finite-element analysis (FEA), multi-body system simulation, digital video and engineering data. Amazingly fast 3D graphics, open architecture design and unparalleled functionality set a new standard for speed and integration of CAE results post-processing.  Attendees will learn new workflows in HyperView 2020 with upfront data loading and our brand-new HyperWorks command language for easier customisation and automisation.

The presentation will showcase:

• Upfront data loading

• HyperWorks command language (hwc)

• Automated reporting with HyperWorks Report

In this webinar we will talk about Feko’s application in the automotive industry. The attendees will see case studies and examples about the followings:

• Windscreen Antennas
• Remote Keyless Entry Systems
• Tire Pressure Monitoring Systems
• Radiation Hazard and SAR
• Wireless Charging
• EMC

OptiStruct is modern structural analysis solver for linear and nonlinear problems under static and dynamic loadings. Now, it has a user-friendly process driven environment to conduct fatigue simulation & optimisation. Attendees will learn the fatigue driven workflows and capabilities of OptiStruct for Fatigue analysis.

The presentation will showcase:

• Workflow of Fatigue analysis
• Approaches of Fatigue in OptiStruct
• Solution based Fatigue
• Fatigue optimisation

In this webinar, we will introduce you to the new functionality for model build and assembly within HyperWorks 2020. Attendees will learn the new workflows for building complex models for multiple attributes and variants, as well as how to control and track revisions in the design and modelling

The presentation will showcase:

• Parts Browser
• Subsystems workflow
• Connectors

EMC regulations and approvals are applicable to almost any industry, the Automotive industry being one of them. Components and systems used in cars are often required to comply with certain standards. This is traditionally achieved through multiple visits to the test labs during the product development. In this webinar we will discuss how simulation can help to reduce the visits to the test houses and submit the products to the test house for the final approval, confidently. In this webinar the attendees will learn about:

• EMC basics
• Different methods available in Feko
• Cable harness analysis
• Radiated emission
• Radiated immunity
• Transient pulses

HyperGraph client enhanced its usability of the product by providing highly efficient core functions, easy to use browser driven workflows, addressing customer critical issues, and improving the performance of readers. For example, apply multiple math operations on a curve, getting top offenders from 1000’s of plotted curves etc...
In this webinar we will present HyperGraph updates and new features.

Below agenda covered:
1) Session browser with Entity Editor
2) Filter entities in the Session browser
3) New Advanced Build Plots dialog
4) 3D input file format support
5) Curve Editor - Reusable plot framework for HyperWorks Desktop
6) Stack Math
7) Extreme curves
8) Curve correlation

In this webinar we will talk about all CFD solvers in Altair (AcuSolve, UltraFluidX, nanoFluidX) , roughly.
And after above, we will show you some attractive use cases which are applied to External Aerodynamics by AcuSolve and ultraFluidX.

Join us in this session if you would like to
1) Find easier to run “External Aerodynamics” simulation
2) Run more accurate “External Aerodynamics” simulation
3) Run multi-physics in External Aerodynamics” simulation
4) Try to find suitable CFD solver for ADAS / WLTP
to get more updates

Altair Radioss is a leading structural analysis solver for non-linear problems under dynamic loadings. It is highly differentiated for scalability, quality, robustness, and consists of features for multi-physics simulation and advanced materials such as composites. Altair Radioss is used across many industries worldwide to improve the crashworthiness, safety, and manufacturability of structural designs.

The presentation will showcase:

• High computing performance, Scalability, Quality and Robustness in RADIOSS
• Industry Standard for Crash, Occupant
• Most Comprehensive Material and Rupture Libraries

Altair HyperWorks has a broad range of NVH functionality for NVH engineers, designed to

reduce the simulation cycle time, freeing CAE engineers to focus on optimizing product

design and performance. NVH Director (NVHD) is the first commercial software solution that

makes full-vehicle NVH simulation possible in the most advanced and streamlined form.

The presentation will showcase:

• NVHD Introduction
• Generic Full Vehicle NVH CAE Process Flow
• Full Vehicle Simulation Methodologies

Altair Inspire is a powerful and easy to use tool for structural analysis, topology optimisation and generative design. Applied early in the product development lifecycle, Altair Inspire accelerates the creation, optimization, and study of innovative, structurally efficient parts and assemblies. In this webinar we will introduce the key tools available within Inspire including:

• Integrated motion analysis
• designing for different manufacturing methods
• casting feasibility checking
• advanced PolyNURB modelling and DfAM

Noise, Vibration, and Harshness (NVH) has always been the top attribute for quality perception by car owners. With the introduction of electric motor to replace ICE, NVH-related issues have become more prevalent now as the cars get ‘quieter’. This webinar will introduce unique features in OptiStruct that are used to reduce the time required to get accurate NVH analysis results and determine the root cause.

The presentation will showcase:

• Workflows you can use to debug your FE model faster
• Fast Eigen Solver and Fast FRF Solver in OptiStruct
• Usage of preloading to get more accurate results

In this webinar, we will introduce optimisation theory along with the different techniques available within Altair OptiStruct for concept and detailed design optimisation. We will also introduce the new Design Explorer functionality in HyperWorks 2020, which enables DoE’s to be run and reviewed directly from the pre-processer.

The presentation will showcase:

• Optimisation theory
• Concept optimisation in OptiStruct
• Detailed optimisation in OptiStruct
• Altair Design Explorer

• Use of inbuilt wizards in MotionView to build suspension and full vehicle handling models
• Creating vehicle handling manoeuvres
• Post processing results
• Flex bodies for generating dynamic stresses
• Load generation & extraction
• Incorporating optimization using HyperStudy

• Casting Introduction.
• What is Inspire Cast?
• Optimize the casting process with Inspire Cast.

• Altair Injection Molding Solution
• Experimental Validation & Industrial Use Cases
• Demonstration
